Model | P2 Pro |
Resolution | 256×192 |
Pixel Size | 12μm |
NETD | ≤40mK@25°C,F#1.0 |
Operating Band | 8~14μm |
Performance | |
Frame Rate | 25Hz |
Operating Temperature | -10°C~55°C(14℉~131℉) |
Storage Temperature | -40°C~85°C(-40 ℉~185℉) |
Power Consumption | 350mW |
Processor | Self-developed ASIC chip |
Lens | |
Focal length | 3.2mm |
Aperture | F1.1 |
FOV | 56.0°x42.2° |
Focusing Mode | Athermalized Prime Lens |
Macro Lens | Adaptable |
Temperature Measurement | |
Measurement Range | -20°C~ 600°C( -4℉~1112℉) |
Measuring Error | ±2ºC (±2% of reading, the greater shall prevail) |
Temperature Correction | Emissivity, distance, environmental temperature |
Shell | |
Size | 27×18×9.8(mm) |
Color | Silver |
Weight | 9g |
Interface | USB type C |
Software Function | |
Palette | White/black-hot + 6 palettes |
Measurement Mode | Point/line/plane temperature measurement |
Information Sharing | Instant picture sharing |
Data analysis | Secondary temperature analysis and processing of images |
Imaging Tool | Android 6.0 and above |
Software Update | Online update |
*Support mainstream smartphone systems, but some systems have not been tested yet.
